2 Copyright Team Orion © 2014
CALIBRATION STEP 1
1) CONNECTIONS
Motor
Servo
Receiver
Vortex R10 ONE
Switch
+ (red)
SET
ST/CH1
TH/CH2
ON/OFF
- (black)
Battery
ON/OFF
Press and
hold the
SET button
1
3
Switch ON
Keep
pressing
the SET
button
LED
2
Release as
soon as soon as
the red LED
starts to blink
