STATUS LED FUNCTION
• In the neutral position, no LED are lit.
• The red LED lights when the car is moving forward,
backwards or when braking.
• At full throttle the green LED is lit.
AUDIO WARNING TONES
1. Input voltage problem: ESC checks the input voltage as
it is switched on, if a problem is detected, the ESC emits
repeatedly two beeps with a 1 second pause and the
green LED ashes simultaneously (xx-xx-xx).
2. Radio signal problem: ESC checks the radio signal input as
it is switched on, if a problem is detected, the ESC emits
repeatedly a beep with a 2 second pause and the green
LED ashes simultaneously (x-x-x).
ESC ADVANCED SETUP
You can adjust certain parameters by using the SET button
located on the ESC’s switch. To adjust the parameters, follow
the procedure below.
A. Switch on the ESC.
B. Press the SET button and release it when the green LED
starts ashing.
C. Use the SET button to cycle between the various
adjustable parameters. The number of green ashes
indicates the parameter, one ash = running mode, two
ashes = drag brake force and so on. The ESC will loop
through all the adjustable parameters.
D. Once the green LED is ashing the number of times
