PROGRAMMING YOUR ESC
Connect the battery
Enter Program Mode
Choose the parameter you want to change
OR
Reset all programmable items
Press the
SET button
for 1s
2
Press the
SET button
for 5s
2
Press the SET button
1 time to select the
1st parameter...
3
...press the SET button
2 times to select the
2nd parameter etc.
3 3
Switch ON
1
Switch OFF
ESC to complete
the procedure
7
LED
blinks
LED blinks 1 time
LED blinks
1 time
LED blinks 2 times
Press the SET button
for 3s to modify
the setting of the
parameter
4
Press the SET button
for 3s to save the
new setting
6
Use the SET button
to change the setting
of the parameter.
Press 1 time
LED blinks
2 times
Press 2 times etc.
5
