MONTAGGIO
� AT TEN ZIO NE
DU RAN TE IL MON TAG GIO NON E’ AM MES SO
NES SUN ESTRA NEO AI LA VO RI.
MONTAGGIO STRUTTURA MOBILE (PIATTAFORMA)
1 - Nell’a rea pre de sti na ta all’in stal la zio ne del pon te pre di spor re 4
ca val let ti di so ste gno aven ti la me de si ma al tez za, ade gua ti al peso
da so ste ne re (250kg. ca dau no ) edi spor li come in fi gu ra (A- B- CD).
Fig.39
2 - To glie re dall’imballo le co lon ne (1-2-3-4),le pe da ne (7-8),la cen -
tra li na idra u li ca (10) e gli ac ces so ri .
3 - Pre di spor re sui 2 ca val let ti (A - D) la pe da na (7) con le due tra -
ver se (5 - 6)
4 - Po si zio na re la tra ver sa (5) sul ca val let to (B) ed av vi tar la sul la
pe da na (7) me dian te le viti (15) M12 x 25 e le ro set te den ta te (16)
Ø12 x 20.
Du ran te que sta fase é im por tan te ve ri fi ca re che le funi sia no in po -
si zio ne cor ret ta (vedi part. “C” in Fig.40) .
5 - Po si zio na re sul le tra ver se (pos.5-6, Fig.39) la pe da na (8).
6 - Ve ri fi ca re la squa dra tu ra e le dia go na li dell’assieme tra ver -
se-pe da ne; quin di ser ra re a fon do le viti (15) di fis sag gio delle pe -
da ne(7-8).
ASSEMBLY
� WAR NING
UNAUT HO RI SED PER SONS MUST NOT BE
ADMITTED DURING ASSEMBLY OPERATIONS.
ASSEMBLY OF MOVABLE STRUCTURE (PLATFORM)
1 - Place 4 trestles of the same height and suitably sturdy to hold
250 kg each, in the area where you intend to install the lift. Position
the trestles as shown in the figure (A- B- C-D).
Fig.39
2 - Remove the posts from the packing (1-2-3-4), together with the
platforms (7-8), the hydraulic power unit (10) and accessories.
3 - Place the platform (7) on two trestles (A - D) together with the
two cross-pieces (5 - 6)
4 - Place the cross-piece (5) on trestle (B) and secure it to the plat-
form (7) using M12 x 25 screws (15) and 12 x 20 toothed washers
(16).
During these operations check that the steel cables are correctly
positioned (see view “C” in fig.40).
5 - Place the platform (8) on the cross-pieces (pos.5-6, fig.39).
6 - Check squareness and the diagonals of the cross-piece - platform
assembly; then, fully tighten the screws (15) securing the platforms
(7-8).
24
15
16 10
9
A
C
B
D
8
7
6
5
3
4
1
2
15
16
