UK
3
1 GUIDE TO THE MANUAL
As regards correct use of the machine, the technical reference
document is the “INSTRUCTION MANUAL AND WARNINGS
supplied with the same.
In order to make the instruction manual conform to the product
described within, it has been drawn up in accordance with the
Directives in force on the date of publication of the document:
Machinery Directive 2006/42/EC, CEI EN 82079, ISO 7000.
Be sure to consult this manual before proceeding with
installation, use and any other work on the machine.
This manual defines the purpose for which the machine was
built and it contains all necessary information to ensure its
proper installation and safe correct operation.
Other technical information that is not included in this manual is
an integral part of the technical file prepared by TECFRIGO
SPA and is available at its facilities.
Constant observance of the regulations it contains will
guarantee personnel and machine safety, low-cost operation
and a longer operating life.
The careful analysis done by hasTECFRIGO SPA made it
possible to eliminate most risks. However, be sure to
follow all the instructions given in this manual. Always refer to
the manual before carrying out any operation.
Safeguard this manual and make sure it is always available
next to the machine or in the nearby vicinity.
TECFRIGO SPA clientswelcomes any comments from
concerning improvements to be made on the machine
and will assess their implementation.
TECFRIGO SPA liable forcannot be held
damage to property or injury to
persons caused by accidents by failure to
comply with the instructions given in this user
and warnings manual.
1.1 SUPPLY AND STORAGE OF THE MANUAL
The manual is supplied in hard copy format.
Keep this manual to hand where it may easily be consulted.
It is the user’s responsibility to keep this documentation intact,
so that it may be consulted throughout the life cycle of the
machine.
If the manual gets lost or destroyed, a copy can be requested
through the firm’s area representative or directly from the
manufacturer.
4.4 ELECTRICAL CONNECTION ............................ 15
5 TECHNICAL DESCRIPTION OF THE DISPLAY
CASE ..............................................................16
5.1 OVERALL VIEW.................................................. 16
5.2 TECHNICAL DATA.............................................. 18
5.2.1 Overall dimensions ................................... 18
5.2.2 Dimensions and arrangement of ice cream
tubs ........................................................... 18
5.2.3 Technical characteristics ........................... 18
6 INSTRUCTIONS FOR USE .............................19
6.1 GENERAL REGULATIONS................................ 19
6.2 COMMISSIONING .............................................. 19
6.3 LOADING THE PRODUCT INTO THE
INTERNAL TRAY ................................................ 19
6.3.1 Positioning the tubs................................... 19
6.4 USE OF THE MACHINE ..................................... 19
6.4.1 Opening and closing the flip-up cover....... 19
6.4.2 Switching the display compartment light on
and off ....................................................... 20
6.4.3 Using the switchboard............................... 20
6.5 SHOWCASE SHUTDOWN ................................ 21
6.6 EMERGENCY STOP .......................................... 21
7 MAINTENANCE ..............................................21
7.1 CLASSIFICATION OF INTERVENTIONS ........ 21
7.2 REQUIREMENTS FOR MAINTENANCE
PERSONNEL ...................................................... 21
7.3 CLOTHING .......................................................... 22
7.4 ROUTINE MAINTENANCE ................................ 22
7.4.1 Cleaning the unit....................................... 22
7.5 EXTRAORDINARY MAINTENANCE................. 22
7.5.1 Cleaning the condenser............................ 22
7.5.2 Replacing the lamp ................................... 23
8 TROUBLESHOOTING ....................................23
9 DISASSEMBLY OF THE SHOWCASE AND
DISPOSAL ......................................................24
9.1 DISMANTLING FOR DEMOLITION .................. 24
9.2 DISMANTLING FOR TRANSFER ..................... 24
9.3 DISPOSAL........................................................... 24
10 WIRING DIAGRAMS .......................................25
10.1 REFRIGERATING SYSTEM DIAGRAM ........... 25
10.2 ELECTRICAL CABLING DIAGRAM .................. 26
CORRECT INSTALLATION FORM .......................27
