16
User’s manual
1..5 schedules – global schedule
These schedules have universal settings for all zones and they cannot be edited in the
external controller (to introduce changes it is necessary to connect to the Internet via the
Internet module).
local schedule.
The type of weekly schedule assigned to a zone is displayed in the main screen (See: Main
screen description – screen area no. 9).
Edit
accuracy of 15 minutes). Separate temperature value is assigned to each time period. The
next step involves setting the temperature value to apply outside the time periods.
The last step involves choosing days of the week when the settings should apply.
Use ▲ to edit the next day and press ▼ to select/deselect.
V.d.4) Calibration
Room sensor calibration should be performed while mounting or after it has been used
Calibration setting range is from -10C to +10C.
V.d.5) Hysteresis
V.e) Pump
L-7 controls the pump operation by activating it (after the delay time) if the temperature
controller disables the pump.
of any zone drops below the pre-set value. Activation delay is used to ensure enough time
for the valve to open.
V.f) Language
This option is used to select the language version.
V.g) Display contrast
This option is used to adjust the display contras to individual user’s needs.
