6
User’s manual
III. Installation
WARNING
Risk of fatal electric shock from touching live connections. Before working on
switched on.
1. Cover (it should be removed to connect the devices to be controlled)
2. Display
3. Buttons
L-7 controller may be installed as a free-standing device or as a panel mountable on a wall.
The controller may be installed on a DIN strip
1
2
3
