Number Name Function descriptions
1 OLEDdisplay
Displaysysteminput/outputportstatus,EDID
management and matrix IP address.
2 IRWindow
IRreceiverwindow,itreceivesIRremotecontrol
signal to control this device.
3
Left/Right/Up/
Down/Menu
Buttons
Aftersystempowerup,theOLEDscreendefaultdisplays
theinputandoutputstatusofthelastpoweroff.
A)OntheinitialOLEDdisplay,youcanpressthe
‘Left’or‘Right’buttonfirstlytoselectoutputport,then
pressthe‘up’or‘down’buttontoselecttheinputport,
thenpressthe‘MENU’buttontoconfirmthisoperation.
B)OntheinitialOLEDdisplay,youcanpressthe‘Up’or
‘Down’buttontocheckeachinputEDIDsetting,press
the‘Menu’buttongobacktotheinitialOLEDdisplay.
C) On the initial OLED display, you can press ‘Menu’
button to operate the following functions by the
combinationofthesefivebuttons,press‘Up’or‘Down’
button to select function:
1.SelectEDID:Pressthe‘Right’button,thenpressthe
‘Up’or‘Down’buttontoselectEDIDasshowedinthe
belowtable.OnceyoucompleteEDIDselection,press
the‘Right’buttonthenpressthe‘Left’or‘Right’button
toselectyourEDIDtocopytowhichinputport,pressthe
‘Right’buttontoconfirmthisoperation.
2.PTP Set:Pressthe ‘Right’button toset PTP mode
(pointtopoint,meansIN1-OUTA,IN2-OUTB,IN3-OUT
C...).
3.SavePreset:Pressthe‘Right’buttontosave
current configuration to preset, press ‘Up’ or ‘Down’
button to select storage location, press the ‘Right’
button to confirm this operation.
4.RecallPreset:Pressthe‘Right’buttontorecall
previouspreset, press ‘Up’ or ‘Down’ button to select
presetyouwant,pressthe‘Right’buttontoconfirmthis
operation.
5.ViewIP:Pressthe‘Right’buttontocheckIP
address and DHCP status.
6.SelectBaud:Pressthe‘Right’button,thenpressthe
‘Up’or‘Down’buttontoselectbaud,pressthe‘Right’
button to confirm this operation.
7. Factory Reset: Press the ‘Right’ button to setting
factory reset status, then press the ‘Right’ button to
confirm this operation or the ‘Left’ button to quit this
operation.
4
Powerand
PowerLED
Longpressthisbuttontopoweron/offdevice.TheLED
willilluminateingreenwhenthedeviceispoweronand
showinredwhenthisdeviceisstandby.
