Techly IDATA HDMI-MXB88 - Operation Controls and Functions; Front Panel

ESD Protection
Human-body Model:
±8kV (Air-gap discharge) , ±4kV (Contact discharge)
Connections
Inputs
8x HDMI Type A [19-pin female]
1xLAN[RJ45,Control]
1x RS-232 [9-pin D-sub, Control]
1x IR EXT [3.5mm Stereo Mini-jack]
Outputs
8x HDMI Type A [19-pin female]
8x Coaxial Audio [RCA]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 483mm (W)×253mm (D)×44.5mm (H)
Weight 3.35kg
PowerSupply
Input:AC100~240V50/60Hz,Output:DC12V/3A
(US/EUstandards,CE/FCC/ULcertified)
PowerConsumption 26.5W (max)
Operating Temperature 0°C~40°C/32°F~104°F
Storage Temperature -20°C~60°C/-4°F~140°F
Relative Humidity 20~90% RH (non-condensing)
5. OPERATION CONTROLS AND FUNCTIONS
5.1 Front Panel
EN - 4
WWW.TECHLY.COM WWW.TECHLY.COM
8X8 HDMI MATRIX
4K@60HZ YUV 4:4:4 18GBPS
