29
9. Technical Specifications
Camera
Colour sensor: 1/ 2.9" CMOS (2 MP)
Minimum illumination: 0.1 Lux @ (F2.0, AGC ON), 0 Lux with 6x IR LED
Viewing angle: 90° horizontal, 55° vertical
Rotation: 355° horizontal, 130° vertical
Lens / Shutter: f=3.6mm / 1/50(1/60)s ~1/100000s
Day / Night mode: built-in IR-CUT filter automatic switching
Video resolution: HD (1920*1080) Smooth (640*480), 15fps
Built-in microphone & speaker
Supports MicroSD(HC/XC) cards up to 128GB (FAT32/ exFAT) (class10)
File size (night; B/W): 4MB/min (32GB = 5.5 days continuous recording)
File size (day; colour): 6.4MB/min (32GB = 3.5 days continuous recording)
H.264/H.265 video compression
G711A/AAC-128-4096Kbps audio compression
Streaming self-adaptive audio compression code
Network Interface: 2.4GHz WiFi
Radiated output power max. 100mW
Reset button, Password protection
Protocol: TCP/IP, UDP, P2P, DNS, DHCP, RTSP, ONVIF
Power supply: DC 5V±10% 1.5A
Power consumption 5W maximum
IR distance ~8m; 850nm (open space)
Alarm function (push message) on your Smartphone
Operating conditions: -10°C~+50°C, humidity 90% or less (non-condensing)
APP "Security Premium": iOS 9.0 or above; Android 7.0 or above / EN, DE,
FR, ES, IT, NL, SE, DK, NO, FI, CZ, PO (06-2020)
Weight / Dimension: 192g / (H) 10.5 x Ø 8.0
Package contents: FullHD WiFi IP PT Indoor Camera TX-146, 1x USB
power adapter 5V/1.5A, 1x USB-to-Micro-USB power cable (2m), 2x Screws
& Dowels, 1x reset pin, 1x mounting bracket with screw, User Manual (short)
