Technical specifications
Power Specific lithium battery 3400mAh
Consumption 400mA
Outline dimension 134 x 74 x 31 mm
Weight 138 g
Environmental temperature –10°C ~ +50°C
Waterproof grade IP55
Placement Hang on out wall
Surface material ABS & hardware accessories
Camera 300000 pixels
View angle 120° wide angle
Night vision 2x IR lamp
Working time ~8 hours continuously
Standby time ~30 days
Charge time ~6 hours
Outdoor
unit
External power 9~16V DC/AC
Power DC 9V
Consumption 400mA
Outline dimension 200 x 150 x 27 mm
Weight 387 g
Environmental temperature –0°C ~ +40°C
Placement Wall hung type or table style
LCD size 7" TFT color screen
Display resolution 640 x 480
Wireless communication mode
2.4GHz
External power DC 9V / 2A
Indoor
monitor
Application distance About 300m in open space
Product Diagram
Outdoor unit
A. Outdoor unit keys
1. Doorbell key“Call”: ring the bell and trigger video taking when pressed.
2. Reset: erase the communication code
