Indoor monitor
Key introduction
A. Indoor monitor Keys (8 key)
1. “OK” key: ON/OFF * Talking * work as confirm key for MENU
2. “↑UP/ Video” key: work as option key for MENU * as video key when
calling or monitoring * as option key when calling extension monitor.
3. “↓DOWN/ Photo” key: work as option key for MENU * as photo key when
calling or monitoring * as entrance key for exposure adjust * as option key
when calling extension monitor.
4. “EXIT / monitor” key: work as monitor key for standby mode * as exit key
for MENU
5. “MENU / unlock” key: work as unlock key when communicating with
outdoor unit * as right moving key for MENU.
6. Brightness
7. Colour
8. Volume: increase and reduce for adjustment.
Installation Guide
Outdoor unit shall be installed at 1.4 ~ 1.7 meter above the floor, and the camera
shall avoid facing the sunlight directly.
