2.2 - DIMENSIONS AND WEIGHT
Weight (kg)
CHG 8 87
1 Water inlet connection 3/4" (male)
2 Water outlet connection 3/4" (male) with air vent valve
3 Water circuit fill/drain - 1/2" male
4 Holes for electric cables
Weight (kg)
CHG 11 120
CHG 15 123
CHG 17 130
1 Water inlet connection 1" (male)
2 Water outlet connection 1" (male) with air vent valve
3 Water circuit fill/drain - 1/2" male
4 Holes for electric cables
1190340
370168
735
30
80
135 100
190 190810
4
3 1 2
340
30
1235
190 190810
370
1190
168
10954
80
535 100
4
3 1
2
