Interactive Channel Guide
When used with a Technicolor COM2000 head end system the DCI401MCS provides your
customers the convenience of an interactive channel guide similar in operations to a DIRECTV
set top box. The guide is accessed by pressing the guide button on the DCI401MCS remote.
Using the arrows on the remote control a viewer can scroll through the guide and tune to the
highlighted channel using the select button.
The IPG requires the following software versions (or newer)
COM46 STO3.03.41
DCI401MCS v01_22_09
Note: V01_22_9 software (and newer) instruction set is to ignore PSIP mapping data.
Channel mapping is done via the .XML file sent to the DCI401MCS. If you are using PSIP
data retain or load software version 01_17_00 or earlier. IPG will not function.
The IPG is not compatible with COM24 cards.
