Technicolor DCI401MCS User Manual

Page 7
Front Panel
Single-color LED for status indication and RF reception acknowledgement
Back Panel
Power input 5 Volt DC
RF input F type connector
RF output F-type connector - Channel 3/4 only
HDMI port (with HDCP)
Channel 3/4 switch Located on back panel
General Data
Product certification UL and FCC
MTBF > 100,000 hours.
Operating temp range +5°C to +45°C
DC pack 100-120V~ @ 60 Hz 5 VDC @ 1.2 A
Power consumption Max 10W (AC power)
Dimensions 4.4” x 3.2” x 0.8” (112 mm x 81 mm x 20 mm)

Technicolor DCI401MCS Specifications

General

Brand	Technicolor
Model	DCI401MCS
Category	Security System
Language	English
