Technics RS-D200

=
2
—_
o}
Zz
iti
Amplifier Deck system: Stereo cassette deck
Track system: 4-track, 2-channel
Heads: REC/PLAY; MX head
Erasing; Double-gap ferrite head
Motor: 1 motor system
Recording system: AC bias
Bias frequency: 80 kHz
Erasing system AC bias
Tape speed: 4.8 cm/sec.
Frequency response:
Metal; 20 Hz~17,000 Hz
30 Hz~16,000 Hz (DIN)
40 Hz~15,000 Hz+3 dB
CrOz 20 Hz~16,000 Hz
30 Hz~15,000 Hz (DIN)
40 Hz~14,000 Hz+3 dB
Normal; 20 H2~15,000 Hz
This unit
Location of this unit and stereo amplifier
30 Hz~14,000 Hz (DIN)
40 Hz~13,000 Hz+3 dB
S/N: (Signal level=max. recording level, CrOz type tape)
Dolby B NR in;
NR out;
Wow and flutter:
Fast Forward and
Rewind Time:
Input sensitivity
and impedance:
66 dB (CCIR)
56 dB (A weighted)
0.07% (WRMS)
+0.14% (DIN)
Approx. 110 seconds with C-60 cassette
tape
If this unit is placed on top or next to the stereo amplifier, a MIC; 0.25 mV/400Q~10kQ
“hum” noise may be heard during tape playback. Refer to the LINE; 60 mV/47 kQ
information below in order to avoid this. Output voltage
elf the stereo amplifier and this unit are placed one above the
other, leave as much space as possible between them, and
place them where there is the least amount of hum.
elf the stereo amplifier and this unit are placed one heside the
and impedance:
LINE;
400 mV/1.5kQ
Power consumption: 10 W
aul : ae Power supply: AC 50 Hz/60 Hz,
other, try reversing their positions, and place them where there 220 V for Europe except United Kingdom,
is the least amount of hum. 110 V/240 V, preset power voltage 240 V
Note: for United Kingdom and Australia.
If this unit is placed on or near the tuner, hum or noise may occur 110 V/125 V/220 V/240 V, preset power
during AM reception. voltage 240 V
; . : Dimensions
@ Using an audio timer (WXHXD): 430x108 228 mm
Timer Weight 3.1 kg
“AC
outlet
(See the operating instruction of the timer.)
eThe configuration of AC power plug may differ according to
area.
To clean, use a soft dry cloth.
If the surfaces are extremely dirty, use a soft cloth, dipped intoa
soap and water solution or a weak detergent solution.
Wring the cloth well before wiping the unit.
Wipe once again with a soft dry cloth.
Never use alcohol, paint thinner, benzine, nor a chemically
treated cloth to clean this unit.
Such chemicals may damage the finish of your unit.
