Technics SA-EH760

Ref. No. Part No. Part Name & Description Pcs Remarks
D747 MA4068L DIODE 1
(GN)
D748 MA165 DIODE 1 (GC)
D749 MA165 DIODE 1
D750 1SS291TA DIODE 1 (GC)
D751,52 1N5402BF DIODE 2
D753-55 RL1N4003N02 DIODE 3
D756,57 MA700 DIODE 2
D758 MA165 DIODE 1
D760 MA165 DIODE 1
D761 RL1N4003N02 DIODE 1
D901,02 1SS291TA DIODE 2
D903,04 MA165 DIODE 2
D905 1SS291TA DIODE 1
D906,07 MA165 DIODE 2
D915 1SS291TA DIODE 1
D934 MA165 DIODE 1
D936 MA165 DIODE 1
D951 LNJ301MPUJAD LED 1
D954 SELS5923C LED 1
D956 SELS5923C LED 1
D961 MA4075M DIODE 1
D973 MA4030M DIODE 1
D974 MA165 DIODE 1
E601,02 SNE1004-2 GND PLATE 2
F1 XBA2C20TB0 FUSE,2A 1
(GN)
F1 XBA2C40TB0 FUSE,4A 1
(GC)
F2 XBA2C20TB0 FUSE,2A 1
(GC)
FL901 RSL0298-F FL 1
IC201 BU4053BCFE2 IC 1
IC401 TA2011S IC 1
IC601 RSN311W64A IC 1
IC901 LC8A524A5N28 IC 1
JK551 SJT3213 CONNECTOR,FAN MOTOR 1 (GC)
JK601,02 RJH5603-1J SP TERMINAL(6P) 2
JK603 RJH2308 JACK,SPEAKER 1
JK701 SJS9236-1 JACK,AC INLET 1
JK901,02 RJJ65MA01 MIC JACK 2
JK903 RJJ37TN02-C JACK,HEADPHONE 1
L601-06 RLQYR73MW1-0 COIL 6
L701 RLQZ371 COIL 1
L901 RLQA100JT1-Y COIL 1
L902 RLQA1R0JT1-Y COIL 1
P1 RPG4791 PACKING CASE(SYSTEM) 1 (GC)
25
