Technics SA-GX505 Service Manual

@ Fine mode indicator (FINE)
This indicator illuminates when the line mode select button is
pressed in the parametric EO mode.
@ ;;;,;;tric EQ system center frequency
It displays the center lrequency of the curves in the
parametric EQ mode arranged by the user with the parametric
EQ system 01 the curve* pre-programmed in this unirs
ml?mqry.
@ Parametric EQ system off indicator (OFF)
This indicator illuminates when the parametric EO system is
Off.
@0 Tone mode indicator (TONE MODE)
This indicator illuminates when the parametric EQltone mode
select button is set lo the tone mode.
@I Parametric EQ mode indicator (P.EQ MODE)
This indicator illuminates when the parametric EQltone mode
select button is set 10 the parametric EO mode.
@ Dolby 3 stereo indicator (DOLBY 3 STEREO)
This indicator illuminates when the Dolby 3 stereo ON/OFF
button is switched ON.
@$ Dolby Pro-Logic Surround indicator
(MIDOLBY SURROUNDS, PRO-LOGIC)
This indicator illuminates when the Dolby Pro-Logic Surround
mode is selected.
0 Manual/fixed preset indicators
(1 2 3 FLAT)
It displays the Type of curve selected with the equalization
preset buttons or fixed preset button in the parametric EO
mode.
0 Parametric EC4 system memory indicator (M)
This indicator illuminates when the parametric EQ system
memory button is pressed in the parametric EQ mode.
0 Parametric EQ system operation select
indicators (MANUAL/FIXED)
One of these indicators will illuminate in accordance with the
fixed preset button or equalization preset buttons setting.
9-
