9
RQT6301
Simple set-up and play
-- dB
MIN
0 dB
MAX
1
Press [ê/I] to turn the unit on.
4
Press [!] to start play.
5
Adjust the volume.
2
Press [<, OPEN/CLOSE] and
insert a CD.
To stop the disc
Press [º].
To pause play
Press [;] during play. The “!” indicator flashes.
Press [;] or [!] to resume play.
“NO DISC” is displayed when a disc isn’t in the player.
Total playing timeTotal number of tracks
Track number Elapsed play
time
Label must face upward.
[EH680] [EH580]
The illustration shows SC-EH580 for the United Kingdom and Eastern Europe.
3
Press [<, OPEN/CLOSE] to close the tray.
Displayed when the unit is in CD mode.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Technics SC-EH580 and is the answer not in the manual?

Technics SC-EH580 Specifications

FRONT SPEAKER

Speaker Specifications IconSpeaker Specifications
super woofer size17 cm cone type
woofer size12 cm cone type
midrange size12 cm cone type
Electrical Characteristics IconElectrical Characteristics
impedance (high)6 �
impedance (low)8 �
input power (music, high)60 W
General IconGeneral
dimensions240�412�259 mm
mass5.8 k�
output sound pressure level87 dB/W (1.0 m)

CENTER SPEAKER

Speaker Specifications IconSpeaker Specifications
woofer size8 cm cone type
tweeter size6 cm cone type
impedance8 �
Electrical Characteristics IconElectrical Characteristics
input power (music)160 W
output sound pressure level86 dB/W (1.0 m)
crossover frequency4 kHz
General IconGeneral
dimensions190�99�166 mm
mass1.8 k�
frequency range100 Hz–22 kHz (�16 dB)

SURROUND SPEAKER

Speaker Specifications IconSpeaker Specifications
full range size8 cm cone type
impedance8 �
input power (music)70 W
General IconGeneral
dimensions140�99�118 mm
mass0.9 k�
output sound pressure level84 dB/W (1.0 m)

SOUND PROCESSOR

EQ/SFP Section IconEQ/SFP Section
center frequency (5-band EQ)70/300/1 k/3.15 k/10 k Hz
level control�2.0, 4.0, 6.0 dB
center frequency (3-band EQ)70/1 k/10 k Hz
Pre-amplifier Section IconPre-amplifier Section
input sensitivity/impedance (VCR)250 mV/15 k�
input sensitivity/impedance (AUX)250 mV/15 k�
output level (VCR REC OUT)150 mV/1.5 k�
General IconGeneral
dimensions293�89�270 mm
mass1.5 k�
delay time20 ms (Fixed)

TUNER AMPLIFIER

Amplifier Section IconAmplifier Section
power output (stereo mode, DIN)2�25 W (1 kHz THD 1 %/6 �)
power output (pro logic mode, DIN)2�25 W (FRONT 1 kHz THD 1 %/6 �)
power output (surround)2�30 W (1 kHz THD 1 %/8 �)
FM Tuner Section IconFM Tuner Section
frequency range87.50–108.00 MHz
sensitivity1.8 �V (IHF usable)
S/N MONO70 dB (75 dB, IHF)
General IconGeneral
power supply (UK, Australia, NZ)AC 230–240 V 50 Hz
power consumption190 W
standby power consumption0.5 W

CD PLAYER

General IconGeneral
dimensions293�89�288 mm
mass2.2 k�
wavelength780 nm

CASSETTE DECK

Deck Specifications IconDeck Specifications
deck systemStereo cassette deck
track system4 track, 2 channel
recording systemAC bias
General IconGeneral
dimensions294�118.5�281 mm
mass2.1 k�
tape speed4.8 cm/s
