Technics SL-1210M5GE - Pitch control ±0% adjustment (PITCH); Brake adjustment (BRAKE)

- Tester
- Frequency counter
9.2. Measurements and Adjustments
9.2.1. Pitch control ±0% adjustment (PITCH)
1. Connect the frequency counter [(+):TP1, (-):GND] and turn the power supply ON.
2. Set the pitch control knob (VR303) to “0” (center position).
(Indicator lights up.)
3. Adjust VR501 so that the output becomes the maximum.(Fig.2)
9.2.2. Brake adjustment (BRAKE)
1. Adjust VR201 so that the rotation at 33-1/3 r/min stops within the stop range after
pressing the stop button.(Fig.1) (Fig.3)
9.3. Alignment points
(Fig.1)
