12. Block Diagram
13. Wiring Connection Diagram
14. Replacement Parts List
Note:
- All parts are supplied by SPC .
- Important safety notice:
- Components identified by mark have special characteristics important for
safety.
- Furthermore, special parts which have purposes of fireretardant (resistors), high-
quality sound (capacitors), low-noise (resistors), etc. are used.
- When replacing any of components, be sure to use only manufacture’s specified
parts shown in the parts list.
- The parenthesized indications in the Remarks columns specify the areas.
Parts without these indications can be used for all areas.
- (E): SL-1210M5GE
- (EB): SL-1210M5GEB
