Technics SL-1210M5GE

- (GN): SL-1210M5GGN
- (PP): SL-1210M5GPP
- Capacity values are in microfarads (uF) unless specified otherwise, P=Pico-
farads (pF) F=Farads (F)
- Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=
1,000k (OHM)
- The marking <RTL> indicates the retention time is limited for this item. After the
discontinuation of this assembly in production, it will no longer be available.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 SFMZ172-01E FC COIL ASS’Y 1
2 SFMG520-31A DRIVE COIL ASS’Y 1
3 SFMGQ20-01 DRIVE COIL COVER 1
4 XTN26+6J SCREW 3
5 N092 SPACER 1
6 REZ1507 WIRE KIT 1
7 REZ1547 WIRE KIT 1
8 RGU2168-S1 KNOB,RESET 2
9 RMQ1194 SHEET 2
10 RMR1501-K BASE 1
11 RMR1502-Q LED PLATE 2
12 XYN3+F8 SCREW 2
18 RGN2481-K NAME PLATE 1 (E)
18 RGN2482-K NAME PLATE 1 (EB)
18 RGN2483-K NAME PLATE 1 (GN)
18 RGN2484-K NAME PLATE 1 (PP)
19 RMR1112-K SHELL STAND 1
20 RMZ0584-1 BARRIER 1 (E,EB,GN)
21 RGK0942AZ-S COVER,STROBE ILLUMINATOR 1
22 RMR1111B-K BASE,OPERATION 1
23 RYQ0309-K KNOB,POWER 1
24 REZ1544 WIRE KIT 1
25 SFUM015-11 LED SPACER 2
26 SFKT015-013E BUTTON,SPEED SELECT(33) 1
27 SFKT015-023E BUTTON,SPEED SELECT(45) 1
28 SFKT015-063A BUTTON,START/STOP 1
29 SFQA122-011 SPRING 1
30 SFQA520-01 SPRING 1
31 SFUM122-03 CUM 1
32 SFUZ122-04 SHEET 1
33 SFXW910J02 WASHER 1
34 SFYB5-32 STEEL BALL 1
35 XTV3+8G SCREW 1
36 XUC3FY WASHER 2
