Technics SL-1500C

TechnicalInformation forHi‐Fi Audio System
Turntablespeed Position‐1 Position‐2
33 After20sec. After70sec.
45/78 After45sec. After90sec.
Service information – Service Mode & Adjustment
c)IfthedetectionpointandLEDblinkareimproper,LEDblinksoncein
“Position‐2”oritblinkstwicein“Position‐1”.
Keeppressing[33]formorethan3secondsandconfirmthedetectionpoint
andLEDblinkisproper.
Autolifterfunctionworksafteralapseofthefollowingtimewhentonearm
reachesthedetectionpointoftherecordend.
a) In case that detection point of the auto lift-up function is in the
range between 51.5mm and 56.5mm, it is set in “Position-1”.
b) In case that detection point of the auto lift-up function is in the
range between 56.5mm and 60.5mm, it is set in “Position-2”.
c) In neither case above, the torn arm or detection sensor may be
defect and thus replace the torn arm unit.
５. Press [33] to confirm whether the detection point is set properly.
a)When the stylus tip reaches in “Position-1”: [33] LED
blinks once and it repeats 3 times a second.
b)When the stylus tip reaches in “Position-2”: [33] LED
blinks twice and it repeats 3 times a second.
Position‐1
Position‐2
500ms:ON 500ms:OFF
3times
100ms:ON
700ms:OFF
100ms:OFF
100ms:ON
3times
18
