Technics SL-1500C

TechnicalInformation forHi‐Fi Audio System
Question Answer
Nosoundorsoundisweak
・ AredeviceconnectionsandPHONOorexternaloutputterminalconnectionscorrect?
‐ ConnectthePHONOoutputterminalswiththeamplifier’sPHONOinputterminals.
‐ Connecttheexternaloutputterminalstotheamplifier’sexternalinputterminals.
・ Istheexternaloutputswitchcorrectlyset?
‐ Whenconnectingtheexternaloutputterminals,settheexternaloutputswitchto“ON”.
Autolift‐updoesnotfunctionor
thetonearmisliftedduringplay
・ Istheautolift‐upswitchcorrectlyset?
‐ Theautolift‐upswitchtoON.
・ Fortheautolift‐upfunctiontooperateappropriately,thecuelevermustbe completely
loweredafterthetonearmisreturnedtothearmrestfollowingtheendofplay.
・ Dependingontherecord,itmaytakesometime(uptoapprox.90seconds)
fortheautolift‐uptooperateaftertheplayfinishes,oritmayoperatewhilethe
recordisstillplaying.Ifthetonearmisliftedduringplay,settheautolift‐upswitch
to“OFF”.
Low,continuoussound(hummingor
buzzingnoise)isheardduringplay
・ ArethereotherappliancesortheirACmainsleadnearthestereoconnectioncable?
‐ SeparatetheappliancesandtheirACmainsleadfromthisunit.
・ Istheearthleadconnected?
‐ WhenconnectingthePHONOoutputterminals,correctlyconnectthePHONOearthlead.
・ AreboththePHONOterminaloutputandexternaloutputterminalssimultaneouslyconnectedto theconnecteddevice?
‐ Connectoneortheother.
Speedselectbutton[33]or[45]
blinks
・ Performthefollowingoperationswhenthespeedselectbutton[33]or[45]blinks.Thesymptommaybeimproved.
1)Press[PowerON/OFF]toOFF.
2)Pulloutthepowerplug,waitforthreesecondsormore,andtheninserttheplugagain.
3)Press[PowerON/OFF]toturntheunitonandpress[START‐STOP]torotatetheturntable.
HowtoplaySP(78rpm)records
・ Pressthespeedselectbuttons[33]and[45]atthesametime(78rpm:[33]LEDand[45]LEDareturnedonsimultaneously)
Service information – FAQ
リフトアップ
スイッチ
Autolift‐up
switch
External
output
terminal
External
output
switch
PHONO
output
terminal
PHONOearth
terminal
