Technics SL-DZ1200PP

Pin
No.
Terminal
Name
I/O Function
87 C_DATA1 I Not used. (’L’)
88 C_DATA2 I Not used. (’L’)
89
C_DATA3
I Not used. (’L’)
90 CGND3 P DE
91 IREF_B - Not used.
92 DAOUT_B - Not used. (’Open’)
93 V
SS
A1 P AE
94 V
DD
A1 P Power supply
95 BIAS_B I VIDEO bias voltage (it is
GND connection at 0.1 F)
96 VREF_RGB I Not used.
97 IREF_G - Not used.
98 DAOUT_G - Not used. (’Open’)
99 V
SS
A2 P AE
100 V
DD
A2 P Power supply
101 BIAS_G I VIDEO bias voltage (it is
GND connection at 0.1 F)
102 V
SS
3V P Power supply
103 V
DD
3V P Power supply
104 IREF_R - Not used.
105 DAOUT_R - Not used. (Open)
106 V
SS
A3 AE
107 V
DD
A3 P Power supply
108 BIAS_R I VIDEO bias voltage (it is
GND connection at 0.1 F)
109 C_DATA4 I Not used. (’L’)
110 C_DATA5 I Not used. (’L’)
111 C_DATA6 I Not used. (’L’)
112 C_DATA7 I Not used. (’L’)
113 C_DATA8 I Not used. (’L’)
114 C_DATA9 I Not used. (’L’)
115 C_DATA10 I Not used. (’L’)
116 C_DATA11 I Not used. (’L’)
117 CV
DD
4 P Power supply
118 C_PCLK I Not used. (’L’)
119 CGND4 P DE
120 C_VSYNC - Not used. (’H’)
121 C_HSYNC - Not used. (’H’)
122 C_FIELD - Not used. (’H’)
123 LCD_SCLK - Not used. (Open)
124 LCD_DO7 - Not used. (Open)
52
