Technics SL-DZ1200PP

Pin
No.
Terminal
Name
I/O Function
164 SDR_A0 P SDRAM address bus
165 DGND5 P DE
166 SDR_DQ31 I/O SDRAM data bus
167 SDR_DQ30 I/O SDRAM data bus
168 SDR_DQ29 I/O SDRAM data bus
169 SDR_DQ28 I/O SDRAM data bus
170 SDR_DQ27 I/O SDRAM data bus
171 SDR_DQ26 I/O SDRAM data bus
172 SDR_DQ25 I/O SDRAM data bus
173 CV
DD
5 P Power supply
174 CGND5 P DE
175 SDR_DQ24 I/O SDRAM data bus
176 SDR_DQ23 I/O SDRAM data bus
177 SDR_DQ22 I/O SDRAM data bus
178 SDR_DQ21 I/O SDRAM data bus
179 SDR_DQ20 I/O SDRAM data bus
180 SDR_DQ19 I/O SDRAM data bus
181 SDR_DQ18 I/O SDRAM data bus
182 SDR_DQ17 I/O SDRAM data bus
183 SDR_DQ16 I/O SDRAM data bus
184 SDR_DQ15 I/O SDRAM data bus
185 SDR_DQ14 I/O SDRAM data bus
186 SDR_DQ13 I/O SDRAM data bus
187 SDR_DQ12 I/O SDRAM data bus
188 SDR_DQ11 I/O SDRAM data bus
189 DV
DD
6 P Power supply
190 DGND6 P DE
191 SDR_DQ10 I/O SDRAM data bus
192 SDR_DQ9 I/O SDRAM data bus
193 SDR_DQ8 I/O SDRAM data bus
194 SDR_DQ7 I/O SDRAM data bus
195 SDR_DQ6 I/O SDRAM data bus
196 SDR_DQ5 I/O SDRAM data bus
197 SDR_DQ4 I/O SDRAM data bus
198 SDR_DQ3 I/O SDRAM data bus
199 DV
DD
9 P Power supply
200 SDR_DQ2 I/O SDRAM data bus
201 SDR_DQ1 I/0 SDRAM data bus
202 SDR_DQ0 I/O SDRAM data bus
203 CV
DD
6 P Power supply
204 CGND6 P DE
54
