Ref. No. Part No. Part Name & Description Pcs Remarks
C2032-34 F1H1H104A783 50V 0.1U 3
C2035 ECEA1HKA4R7 50V 4.7U 1
C2036 ECEA1VKS470 35V 47U 1
C2037 F1H1H104A783 50V 0.1U 1
C2038 ECJ1VB1H562K 50V 5600P 1
C2039 F1H1H104A783 50V 0.1U 1
C2041 ECEA1AKS470 10V 47U 1
C2042 ECEA1EKA330B 25V 33U 1
C2043 ECJ1XB1C473K 16V 0.047 1
C2044 F1H1H104A783 50V 0.1U 1
C2045 ECEA1EKA330B 25V 33U 1
C2047 ECJ1XB1C473K 16V 0.047 1
C2048 ECEA1EKA330B 25V 33U 1
C2050 ECEA1HKS010 50V 1U 1
C2051 ECEA0JKA330B 6.3V 33U 1
C2052 ECJ1VB1H103K 50V 0.01U 1
C2053 ECEA1CKN100 16V 10U 1
C2054,55 ECJ1VF1C104Z 16V 0.1U 2
C2056 F1D1H1040002 50V 0.1U 1
C2057-59 ECJ1VF1C104Z 16V 0.1U 3
C2060,61 ECEA1CKN100 16V 10U 2
C2062 ECA1EAK470XB 25V 47U 1
C2063 ECJ1VF1C104Z 16V 0.1U 1
C2064 ECJ1VB1H102K 50V 1000P 1
C2066 ECJ1VF1C104Z 16V 0.1U 1
C2068-71 ECJ1VF1C104Z 16V 0.1U 4
C2072 ECJ1VC1H331J 50V 330P 1
C3101,02 ECEA1AKS221 10V 220U 2
C3103-05 F1D1H1040002 50V 0.1U 3
C3106-11 ECBT1C222MR5 16V 2200P 6 F1D1C222A002
C3401,02 F1D1H1040002 50V 0.1U 2
CN1 K1KA11A00156 CONNECTOR(11P) 1
CN2 K1MN45B00013 CONNECTOR(45P) 1
CN3 K1MN17A00041 CONNECTOR(17P) 1
CN4 K1NA09E00028 CONNECTOR,SD CARD 1
CN5 K1KA13A00122 CONNECTOR(13P) 1
CN6 K1KA03A00176 CONNECTOR(3P) 1
CN7 K1MN24A00055 CONNECTOR(24P) 1
CN9 K1KA12A00312 CONNECTOR(12P) 1
CN12 K1KA07A00190 CONNECTOR(7P) 1
CN801 VJP3331B004 CONNECTOR(4P) 1 K1KA04B00079
CN1301 REX1176 CONNECTOR(12P)(WITH WIRE) 1
CN1901 REX1177 CONNECTOR(3P)(WITH WIRE) 1
CN2001 K1KA03A00213 PLUG(3P) 1
CN2007 RJS2A5624 CONNECTOR(24P) 1 K1MN24A00030
CN2013 TJSF26112 CONNECTOR(12P) 1 K1KA12A00068
CN2014 RJP14G18ZA PLUG(14P) 1 K1KA14A00051
CN2104 VJP3331B008 CONNECTOR(8P) 1 K1KA08B00128
CN2201 REX1180 CONNECTOR(2P)(WITH WIRE) 1
CN2301 REX1175 CONNECTOR(7P)(WITH WIRE) 1
CN2302 VJP3331B002 CONNECTOR(2P) 1 K1KA02B00049
CN2303 K1KA02B00045 CONNECTOR(2P) 1
CN2319 K1KA03B00049 CONNECTOR(3P) 1
79
