Ref. No. Part No. Part Name & Description Pcs Remarks
L1404 J0JKB0000003 COIL 1
L2001 ELELN100KA COIL 1
L2002,03 G0BYYYY00016 COIL 2
L2006 G0BYYYY00016 COIL 1
L3101 J0JKB0000003 COIL 1
L3301 J0JKB0000003 COIL 1
LB1122 J0JKB0000003 COIL 1
P1 RPG6709 PACKING CASE 1 (PP)
P1 RPG6713 PACKING CASE 1 (EG)(EB)
P1 RPG6710 PACKING CASE 1 (EP)
P1 RPG6712 PACKING CASE 1 (GN)
P2 RPN1645 CUSHION 2
P3 RPQ1607 PAD 1
P4 RPF0378 PROTECTION BAG 1
P5 XZB10X30C03Z PROTECTION BAG 2
P6 XZB25X34C03X PROTECTION BAG 1
P7 SPP723-1 PROTECTION BAG 1
PCB1 REP3599A-M MAIN P.C.B. ASS’Y 1 [RTL]
PCB2 REP3601BA-S POWER P.C.B. ASS’Y 1 [RTL](PP)
PCB2 REP3601CA-S POWER P.C.B. ASS’Y 1 [RTL](EG)(EB)(EP)(GN)
PCB3 REP3601AB-S JACK P.C.B. ASS’Y 1 [RTL]
PCB4 REP3601AD-S CP5 P.C.B. ASS’Y 1 [RTL]
PCB5 REP3601AE-S CD LIGHT P.C.B. ASS’Y 1 [RTL]
PCB6 REP3601AF-S CD OP SW P.C.B. ASS’Y 1 [RTL]
PCB7 REP3601AG-S EJECT P.C.B. ASS’Y 1 [RTL]
PCB8 REP3600AA-S CP1 P.C.B. ASS’Y 1 [RTL]
PCB9 REP3600AB-S CP2 P.C.B. ASS’Y 1 [RTL]
PCB10 REP3600AC-S CP3 P.C.B. ASS’Y 1 [RTL]
PCB11 REP3600AD-S LCD CN P.C.B. ASS’Y 1 [RTL]
PCB12 REP3600AF-S MOTOR P.C.B. ASS’Y 1 [RTL]
PCB13 REP3600AJ-S SENSOR P.C.B. ASS’Y 1 [RTL]
PCB14 REP3600AK-S STROBE P.C.B ASS’Y 1 [RTL]
PCB15 REP3600AL-S PC ON P.C.B. ASS’Y 1 [RTL]
Q1 2SD0601A TRANSISTOR 1
Q2,Q3 XP151A12A2MR FET 2 B1DFBC000002
Q4-Q6 B1GBCFQQ0005 TRANSISTOR 3
Q7 2SB0709ARL TRANSISTOR 1
Q8 2SD0601A TRANSISTOR 1
Q9 B1GBCFQQ0005 TRANSISTOR 1
Q10,11 B1DHAC000002 TRANSISTOR 2
Q1200 PC123ZY2 PHOTO COUPLER 1
B3PBA0000078
Q2001 2SB0709ARL TRANSISTOR 1
Q2002,03 2SD0601A TRANSISTOR 2
Q2004 2SD592AR TRANSISTOR 1 2SD0592AR
Q2005 2SB621A-R TRANSISTOR 1 2SB0621AH
Q2006 2SD592AR TRANSISTOR 1 2SD0592AR
Q2007 2SB621A-R TRANSISTOR 1 2SB0621AH
Q2008 2SC1845EFTA TRANSISTOR 1 B1AABL000015
Q2009 2SC2458GR TRANSISTOR 1 2SC26340V
Q2010-13 2SD0601A TRANSISTOR 4
