Technics SL-DZ1200PP User Manual

Ref. No. Part No. Part Name & Description Pcs Remarks
VEP62121B
201 VXB0129 HOLDER 1 (PAS)
202 VXJ0226 DRIVE SHAFT 1 (PAS)
203 VEM0746 SPINDLE MOTOR ASS’Y 1 (PAS)
204 VEM0705 DRIVE MOTOR 1 (PAS)
205 VXK1518 TRAVERSE CHASSIS 1 (PAS)
206 VXL2930 ROLLER SHAFT 1 (PAS)
207 VHD1313 SCREW 1 (PAS)
208 VMB3368 FLOATING SPRING F 2 (PAS)
209 VMB3369 FLOATING SPRING R 1 (PAS)
210 VMB3370 BALANCE SPRING 2 (PAS)
211 VMB3666 SPRING 1 (PAS)
212 VMG1325 INSULATOR R 1 (PAS)
213 VMG1256 INSULATOR F 2 (PAS)
214 VMK0490 MAIN FRAME 1 (PAS)
215 VMK0491 UPPER FRAME 1 (PAS)
216 XQN2+AM3 SCREW 2 (PAS)
217 RMC0294 SPRING 1 (PAS)
218 RAF0143A-Z OPTICAL PICK-UP 1
(PAS)
219 XQN17+BG15 SCREW 1 (PAS)
220 VDG1384 GEAR 1 (PAS)
221 VDG1387 WHEEL 1 (PAS)
222 VDG1388 CHANGE GEAR 1 (PAS)
223 VDG1389 CHANGE LEVER GEAR 1 (PAS)
224 VDG1390 SLOWDOWN GEAR A 1 (PAS)
225 VDG1391 SLOWDOWN GEAR B 1 (PAS)
226 VDG1392 SLOWDOWN GEAR C 1 (PAS)
227 VDG1393 GEAR 1 (PAS)
228 VDG1394 ROLLER TRANSFER GEAR A 1 (PAS)
229 VDG1395 ROLLER TRANSFER GEAR B 1 (PAS)
230 VDG1397 GEAR 1 (PAS)
231 VDK0162 LOCK CUM L 1 (PAS)
232 VHD1304 SCREW 2 (PAS)
233 VHD1331 SCREW 1 (PAS)
234 VMA0D36 PLATE 1 (PAS)
235 VMB3667 SPRING 1 (PAS)
236 VMB3372 SPRING 1 (PAS)
237 VMB3375 SPRING L 1 (PAS)
238 VMB3376 SPRING R 1 (PAS)
239 VMC1555 PLATE 1 (PAS)
240 VML3449 CHANGE LEVER 1 (PAS)
241 VML3450 LEVER 1 (PAS)
242 VML3452 TRAVERSE HOOK 1 (PAS)
243 VML3453 LOADING HOOK 1 (PAS)
244 VML3457 SIDE ARM R 1 (PAS)
245 VMK3458 SIDE ARM L 1 (PAS)
246 VMM0438 SIDE LINK 1 (PAS)
247 VMZ2961 PROTECTION SHEET 1 (PAS)
248 XTW2+6S SCREW 1 (PAS)
249 VHD1305 SCREW 2 (PAS)
250 VMA0D35 DRIVE MOTOR ANGLE 1 (PAS)
251 VEE0J05 LEAD WIRE ASS’Y 1 (PAS)
90
