Ref. No. Part No. Part Name & Description Pcs Remarks
C60 F1H1H472A238 50V 4700P 1 (PAS)
C61 ECJ1VB1H102K 50V 1000P 1 F1H1H102A009
C62,63 F1J1C3340005 16V 0.33U 2 (PAS)
C67 ECUV1E273KB 25V 0.027U 1
C68 F1H1H471A190 50V 470P 1 (PAS)
C71 ECJ1VB1H122K 50V 1200P 1
C101 F1H1C104A009 16V 0.1U 1 (PAS)
C102,03 F2G0J1010005 6.3V 100U 2 (PAS)
C104 F1H1C104A009 16V 0.1U 1 (PAS)
C105 F2G0G1010003 4V 100U 1 (PAS)
C106 F1H1A1050029 10V 1U 1 (PAS)
C107 F1H1C104A009 16V 0.1U 1 (PAS)
C108 F2G0G4700003 4V 47U 1 (PAS)
C109-17 F1H1C104A009 16V 0.1U 9 (PAS)
C120 F1H1C104A009 16V 0.1U 1 (PAS)
C123 F1H1A1050029 10V 1U 1 (PAS)
C124 F1H1C104A009 16V 0.1U 1 (PAS)
C125 F2G0J4700005 6.3V 47U 1 (PAS)
C126-28 F1H1C104A009 16V 0.1U 3 (PAS)
C129 F1H1C104A042 16V 0.1U 1
C131 ECJ1VB1H102K 50V 1000P 1 F1H1H102A009
CN1 K1MN16B00036 CONNECTOR(16P) 1 (PAS)
CN2 K1KA02B00051 CONNECTOR(2P) 1
CN3 K1MN11B00051 CONNECTOR(11P) 1 (PAS)
CN4 RJS2A5945T CONNECTOR(45P) 1 K1MN45B00004
CN5 K1MN05B00035 CONNECTOR(5P) 1 (PAS)
D101-04 B3EB00000009 PHOTO SENSOR 4 (PAS)
D105 DAP202U DIODE 1
IC1 AN8882SB-E1 IC 1 (PAS)
IC2 AN77L05M IC 1
IC3 MN6627482WA IC 1 (PAS)
IC4 C0GBF0000004 IC 1
IC5 C0GBF0000007 IC 1 (PAS)
IC101 C1BB00000598 IC 1 (PAS)
IC102 C2BBGE000781 IC 1
IC103 C3ABHG000008 IC 1 (PAS)
IC104 C0JBAZ001251 IC 1
IC105 C0EBH0000105 IC 1 (PAS)
IC106 C0DBZGE00002 IC 1 (PAS)
L101-03 J0JJC0000011 COIL 3
PCB100 VEP62121B SERVO P.C.B. ASS’Y 1 [RTL]
Q1 2SA1037AKTXR TRANSISTOR 1 B1ADCF000001
Q2,Q3 B1GBCFNA0010 TRANSISTOR 2
Q4,Q5 B1GDCFJG0003 TRANSISTOR 2 (PAS)
Q101 DTA143XU TRANSISTOR 1
R1 ERJ3GEYJ221V 1/10W 220 1
R2 ERJ3GEYJ220V 1/10W 22 1
92
To Next Page
