FEmitted vibration level
1. Test code
Measurement method
The measurements were taken according to the regulations of standard ISO 5349-1 (2001).
Measurement equipment used:
• spectrum analyser M+P international Vib Pilot VP8
• accelerometer PCB Piezotronics 356A32
Material used for marking:
• XM700 handheld machine
• power supply or battery (standard)
• magnetic tray to hold the plate
The assembly is placed on a concrete floor.
A new plate is used for each test.
Readings are taken at the 3 handle(s), varying the marking force and speed (handles: main, side, upper).
2. Vibration information
The maximum vibration is generated on the upper handle at maximum marking force and speed.
The maximum vibration to which the hand/arm system is exposed is less than 2.2 m/s².
