TechniSat AUDIOMASTER MR2 User Manual

30
6.6 Using the audio input
It is possible to play sound from external devices using the analogue audio output.
> Connect the external device to the AUX IN connection (11), (3.5mm jack) on the device rear.
> In Source selection tap the AUX IN item.
To set the volume optimally, use the volume control both on the device and on the connected external
device.
Please note that if the volume on the connected device is very low, while the speakervolume setting is
higher, annoying noises/background noise will be amplified and, therefore, will clearly be heard. It is
recommended that you set the speaker volume, e.g. on an Internet radio station, switch to the audio input
and then to adjust the volume of the connected device in such a way that the overall volume of the audio
input corresponds approximately to the volume of the Internet radio station. In this way, you can also
avoid considerable differences in volume when switching between the speaker functions.
6.7 Other buons on the device
The following buttons can be found on the top of the device:
> VOL - (10), volume control, down (TECHNISOUND MR2 only)
> VOL +(9), volume control, up (TECHNISOUND MR2 only)

TechniSat AUDIOMASTER MR2 Specifications

General

Type	Home audio micro system
Product color	Black, Silver
Certification	CE
Recommended usage	Universal
Card reader integrated	No
Multi-Room Streaming (MRS) support	Yes
Speaker type	-
Number of drivers	2
Speaker enclosure	Closed
Speaker placement	Tabletop/bookshelf, Wall-mountable
Audio output channels	1.0 channels
DC input voltage	18 V
Mobile operating systems supported	Android, iOS
Power source type	AC
Connectivity technology	Wired & Wireless
RMS rated power	60 W
Current	2.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.6 W

Weight and Dimensions

Depth	127 mm
Width	290 mm
Height	190 mm
Weight	2900 g
Package depth	185 mm
Package width	350 mm
Package height	260 mm
Package weight	3800 g
