TechniSat AUDIOMASTER MR2 User Manual

33
EN
FR
IT
NL
NW
DK
PL
CZ
SK
7.2 Device selection
In the event that you have, in the meantime, used another device with the MyDigitRadioPro app, you can, at
any time, return to the AUDIOMASTER or TECHNISOUND MR2.
> To do so, tap the device designation in the very top line of the Now running view.
> Now select your Device.
After this, the app automatically returns to the Now running view.
7.3 Control elements
> Use the control elements to pause playback or to change to the next or previous track.
> Use the Volume bar on the boom edge of the image to adjust the volume.
> By moving the progress bar, you can skip to dierent parts of a track whilst it is playing.
> By tapping the Random mode and Repeat buons, you can switch the respective function on or o.
The control elements available depend on the selected source. In general, with Internet radio, it is not
possible to pause or skip to specific parts.
7. 4 Seings
This menu allows you to carry out different settings and to view information.
> To open the seings, tap the Gear wheel icon at the top right image edge.

TechniSat AUDIOMASTER MR2 Specifications

General

Type	Home audio micro system
Product color	Black, Silver
Certification	CE
Recommended usage	Universal
Card reader integrated	No
Multi-Room Streaming (MRS) support	Yes
Speaker type	-
Number of drivers	2
Speaker enclosure	Closed
Speaker placement	Tabletop/bookshelf, Wall-mountable
Audio output channels	1.0 channels
DC input voltage	18 V
Mobile operating systems supported	Android, iOS
Power source type	AC
Connectivity technology	Wired & Wireless
RMS rated power	60 W
Current	2.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.6 W

Weight and Dimensions

Depth	127 mm
Width	290 mm
Height	190 mm
Weight	2900 g
Package depth	185 mm
Package width	350 mm
Package height	260 mm
Package weight	3800 g
