TechniSat DIGITRADIO 370 CD IR User Manual

79
DE
EN
FR
NL
> Then select your WLAN network.
You can now choose whether to use the WPS function or whether you prefer
to enter your WLAN password manually.
> If you would like to use the WPS function, launch it on your router first as per
its instruction manual and then select [Press WPS Buon] in the network
wizard.
Please observe the display overlays. The connection process is generally
completed in a few seconds and the WLAN connection can be used.
> If you wish to enter your WiFi password manually, or if your router does not
support the WPS function, select [Skip WPS].
> Then enter the password using the displayed virtual keyboard. Then select
and press the ENTER buon. If the password entered is correct a
connection to the network is now established. To cancel the entry, select
and press the ENTER buon. If you make a typing error you can
delete the last leer entered using .
When the virtual keyboard is displayed, you can use / on the remote
control for navigation. The / buons move the highlight upwards and
downwards, the / buons move the highlight to the right and le.
The entered password will then be verified. This process is generally
completed in a few seconds and the WLAN connection can then be used.
The signal bar in the status bar of the display indicates whether the
connection has been established.
16.3.1.2 Configuration via the WPS function
This establishes a direct connection to the router. Selecting and/or entering a WLAN
network (SSID) and password is not required.
> Start the WPS function on your router as per the instruction manual.
> Then select [PBC WLAN Set-up] to launch the connection process.
Please observe the display overlays. The connection process is generally
completed in a few seconds and the WLAN connection can be used.
Alternatively the [PIN] function can be used if this function is supported by
the router.
16.3.1.3 Manual configuration
> Select [Manual seings] then [Wireless] to launch manual configuration.

TechniSat DIGITRADIO 370 CD IR Specifications

General

FM band range	87.5 - 108 MHz
Preset stations	Yes
Supported radio bands	DAB+, FM, PLL, UHF
Preset stations quantity	40
Internet radio services supported	Spotify
Bluetooth version	4.2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Apple docking	-
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Type	Home audio mini system
Product color	Black
Volume control	Rotary
Display type	TFT
Disc types supported	CD, CD-RW
Audio formats supported	MP3
RMS rated power	10 W
Number of speakers	2
Power source	AC
Input voltage	230 V
Input frequency	50 Hz

Weight and Dimensions

Depth	210 mm
Width	350 mm
Height	120 mm
Weight	2750 g
Package depth	280 mm
Package width	425 mm
Package height	175 mm
Package weight	3540 g
