> During the next step you must select via which source the time is to be
synchronised (for more information refer to Section 18.3).
If you have selected [Update from the Net], you must then enter the time
zone and summertime/wintertime.
Depending on the time and date seings, some of the network seings are now
performed.
> Select whether the WLAN connection should remain active in standby mode
as well. Press the OK buon.
> Ensure that the device is within the reception range of the desired WLAN
network and that you have the access data. In some cases it may be
necessary to carry out some seings on the router. In this case, please refer
to the corresponding instruction manual.
Aer a search for available wireless networks you are shown the result.
> Select the desired wireless network and confirm the selection with OK. Select
Skip WPS to enter the password.
If it is a protected network you will be asked to enter the corresponding
access key.
> To do this, mark the respective character.
> Enter the selected character by pressing the OK buon.
Proceed in this way until the complete access key can be seen in the input
field.
To cancel the input, select and press the OK buon. If you make a
mistake, you can delete the last leer you entered by pressing
.
> Then select and press the OK buon. If the password entered is
correct, a connection to the network is now established.
> When [Set-up wizard completed] appears on the display, press the OK
buon.
18.8 Info
> Press the MENU buon and then select [Main Menu > System Seings >
Info].
> Confirm by pressing OK.
> The soware version is shown.
> You can return to the menu by pressing the MENU buon.

TechniSat DIGITRADIO 602 Specifications

General

Radio type	Internet
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Frequency range	25 - 18000 Hz
RMS rated power	70 W
Number of built-in speakers	2
Display type	OLED
Display diagonal	2.7 \
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Projection	No
Antenna type	External
Product color	Anthracite, Silver
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Power source	AC
AC input voltage	230 V
DC input voltage	18 V
AC input frequency	50 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package depth	267 mm
Package width	470 mm
Package height	263 mm
Package weight	6200 g

Weight and Dimensions

Depth	215 mm
Width	400 mm
Height	170 mm
Weight	4970 g
