Page #74 background imageLoading...
Page #74 background image
74
18.9 Display backlight
It is possible to set the display brightness both for operation as well as for the
standby mode.
> Press the MENU buon and then select [Main Menu > System Seings >
Backlight].
> Select [Operation] or [Standby] to apply the seing for operating mode or
standby mode.
> You can now set the brightness in three steps from High to Medium to Low
and O (only in standby mode).
> Confirm the selection with OK.
18.10 Data protection information
> Press the MENU buon and then select [Main Menu > System Seings >
Data Protection].
Here you will find a link to the current data protection information relating to your
device.
19 Charging function for external devices
The DIGITRADIO 602 has a wired and wireless (to Qi standard) charging function for
external devices such as mobile phones and smartphones.
Caution: Do not use both variants at the same time. This can cause damage
to your devices.
19.1 Wired charging of external devices
Use the original charging cable (USB) for your external device and insert the USB
plug into the USB port (1) on the front of the DIGITRADIO 602. The external device
can be charged at a maximum of 5 V and 1 A.
19.2 Wireless charging of external devices
If your external device has a wireless charging function (wireless charging to QI
standard), you can place it on the charging mat on the top of the DIGITRADIO
602. The display of your external device must be facing upwards when doing so.
If correctly orientated, the charging process will begin automatically. Please refer
to the instruction manual for your external device for more information on wireless
baery charging.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TechniSat DIGITRADIO 602 and is the answer not in the manual?

TechniSat DIGITRADIO 602 Specifications

General IconGeneral
Radio typeInternet
Tuner typeAnalog & digital
FM band range87.5 - 108 MHz
DAB band range174 - 240 MHz
Supported radio bandsDAB+, FM
Radio Data System (RDS)Yes
Frequency range25 - 18000 Hz
RMS rated power70 W
Number of built-in speakers2
Display typeOLED
Display diagonal2.7 \
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs1
Headphone connectivity3.5 mm
ProjectionNo
Antenna typeExternal
Product colorAnthracite, Silver
Volume controlRotary
Internet radio services supportedSpotify
On Screen Display (OSD) languagesDAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Power sourceAC
AC input voltage230 V
DC input voltage18 V
AC input frequency50 Hz
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)5 - 90 %
Package depth267 mm
Package width470 mm
Package height263 mm
Package weight6200 g
Weight and Dimensions IconWeight and Dimensions
Depth215 mm
Width400 mm
Height170 mm
Weight4970 g
