TechniSat DIGITRADIO 602 User Manual

75
DE
EN
FR
NL
DE
EN
FR
NL
20 Cleaning
To prevent the risk of electric shock, you must not clean the device using a
wet cloth or under running water. Remove the mains plug prior to cleaning!
You must not use scouring pads, scouring powder, or solvents such as alcohol
or petrol.
Do not use any of the following substances: salt water, insecticides, solvents
containing chlorine or acids (ammonium chloride), scouring agents.
Clean the housing using a so, damp cloth. Do not use solvents, spirit,
thinners, etc.; you could damage the surface of the device.
Only clean the display with a so coon cloth. If required, use a coon cloth
with small amounts of non-alkaline, diluted, water-based or alcohol-based
soap solution.
Rub the surface with the coon cloth gently until it is completely dry.
21 Troubleshooting
If the device does not operate as intended, check the table below for information.
Symptom Possible cause/remedy
The device cannot be switched on. The device is not being supplied with power.
Connect the power supply unit correctly to
the socket and to the device.
No sound can be heard. Increase the volume.
The display does not switch on. Disconnect the device from the power supply
and then reconnect it.
Poor reception via DAB+/FM. Change the position of the antenna or the
DIGITRADIO 602.
The device cannot be operated. Disconnect the device from the power supply
and then reconnect it.
External device is not charging via
wireless charging
Change the position of the charging mat until
the charging process begins.
Bad Bluetooth connection and
drop-outs
Do not exceed the maximum range for
Bluetooth of 10 m.
If the malfunction has not been resolved, even aer performing the checks
described, please contact the Technical Hotline.

TechniSat DIGITRADIO 602 Specifications

General

Radio type	Internet
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Frequency range	25 - 18000 Hz
RMS rated power	70 W
Number of built-in speakers	2
Display type	OLED
Display diagonal	2.7 \
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Projection	No
Antenna type	External
Product color	Anthracite, Silver
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Power source	AC
AC input voltage	230 V
DC input voltage	18 V
AC input frequency	50 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package depth	267 mm
Package width	470 mm
Package height	263 mm
Package weight	6200 g

Weight and Dimensions

Depth	215 mm
Width	400 mm
Height	170 mm
Weight	4970 g
