TechniSat DIGITRADIO 650 User Manual

85
DE
EN
FR
NL
23 Technical specifications / manufacturer's instructions
Subject to technical changes and errors.
Operating types Internet, DAB+, FM, Bluetooth, CD, USB,
Spotify, Amazon Music, AUX-In, Line-In
Power supply DC 18 V, 3.3 A via the external mains
adapter provided
Display 3.5" TFT
Frequencies USW: 87.5 - 108 MHz
DAB+ Band III 174 - 240 MHz
Bluetooth V5.0: 2402 - 2480 MHz
WiFi: 802.11 a/b/g/n
2412 - 2472 MHz
5150 - 5725 MHz
(EIRP) transmission power Bluetooth: 3.14 dBm
WiFi: 9.86 dBm
Power consumption in operation max.: 59.4 W
Standby: < 1 W
Standby with network connection: < 2 W
Audio output 70 W RMS (2x 20 W + 1x 30 W)
Output Power Wireless Charging Pad max. 5 W
Operating ambient conditions Temperature: 5 °C ~ 35 °C
Humidity: 5 - 90 % relative air humidity
(non-condensing)
Weight ~ 4.58 kg
Dimensions (W x D x H) 450 x 265 x 140 mm
Technical data for supplied power cable
Manufacturer TechniSat Digital GmbH, Julius-Saxler-
Strasse 3, D-54550 Daun, Germany
Model number BQ60A-1803300-G
Input voltage AC 100 - 240 V
Input AC frequency 50/60 Hz
Output voltage DC 18.0 V
Output current 3.3 A
Output power rating 59.4 W
Average eciency during operation 89.4 %
Eciency under low load 86.7 %
Power consumption under zero load 0.07 W

TechniSat DIGITRADIO 650 Specifications

General

Radio type	Internet
Tuner type	Digital
Supported radio bands	DAB+, FM
Equalizer	Yes
RMS rated power	70 W
Number of built-in speakers	2
Power source	AC, USB
AC input voltage	230 V
DC input voltage	18 V
AC input frequency	50 Hz
Display diagonal	3.5 \
Display resolution	320 x 480 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Headphone connectivity	3.5 mm
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Projection	-
Product color	Silver, White
Package type	Box
Package depth	270 mm
Package width	570 mm
Package height	285 mm
Package weight	7880 g

Weight and Dimensions

Depth	230 mm
Width	500 mm
Height	180 mm
Weight	5940 g
