TechniSat DIGITRADIO Car 1 User Manual

31
E
5.3. Connect the DIGITRADIO with your car radio system
There are 2 ways to connect the device with your car radio system to play audio signals form DAB+ radio, Micro SD
card, Bluetooth or LINE IN.
Via LINE INPUT
If your car radio system supports a LINE Input, we recomment this method to transmit the signals.
In this case, please use the 3,5 mm audio cable, included in delivery content and plug this cable to the LIN OUT
connector (Point 11, chapter 4). Connect the other end of cable with the LINE IN or AUX input of your car audio
system.
VIA FM transmier
The FM transmier function can be used, to wireless transmit the audiosignals to the FM receiver of your car audio
system. Please use this option, if your car audio system has no LINE IN /AUX IN connector.
> Power on the DIGITRADIO.
> Power on your car radio system and select a free FM frequency, which is not used by a radio station.
> Press the and select the same frequency by rotaing the spin buon.
> Press the spin buton to confirm.
Now the can play the audio signals of DIGITRADIO on your FM car radio.
5. Installation

TechniSat DIGITRADIO Car 1 Specifications

General

DAB Radio frequency range	Band III 174- 240 MHz
FM Transmitet r frequency range	87.6 MHz- 107.9 MHz
Bluetooth Modul	ATS V 4.2, A2DP, HFP, AVRCP
Display	VA Display
Power supply	5 Volt 500mA
Micro SD cardreader	Micro SD Card up to 32 GB Fileformat: MP3
LINE IN/LINE Out	Stereo 3, 5 mm Klinke
Accu	800 mAh
Temperature	-20 C0 - + 70 C0

Weight and Dimensions

Dimension	49 X 76.5 X 30.79
