C
B
04206026
A
Adjusting the weight stack cable tension
It is possible to take up some of the slack in the weight stack cable using the adjuster
(C), after loosening the lock nut (B).
For this purpose, you will need to remove the back panel of the weight stack (following
the instructions found in the section Removing the weight stack panel).
WARNING
To pull the cable taut after replacement, it may be helpful, when
tightening the screws (A), to insert a thickness of approx. 10 mm (1/2”)
under the first weight in the weight stack.
