Technogym Element+ Leg Press - Page 23

23
Leg Press
H
G
F
I
cont.
Replacing the weight stack cable
- put in the adjuster (G), and tighten the lock nut (F);
- insert a thickness of approx. 10 mm (1/2”) under the first weight of the weight
stack and remove the pin;
- reassemble the block (I);
- insert the cable and tighten the grub screws (H);
- replace the back panel of the weight stack (following the instructions found in
the section Removing the weight stack panel in reverse order).
