RUN EXCITE-2008: Service & Maintenance Manual - rev. 1.3
Page 6.19
6.5. NO AUDIO SOUND
This error can be due to incorrect machine configuration, or to problems with the audio signal.
Is the TV standard correctly
conf igured?
Correctly conf igure the
"TV Standard"
parameter
NO
YES
NO AUDIO SOUND
1
Replace the headphone jack.
Does it work?
Defectiv e headphone
jack
YES
NO
Replace headphone
connection cable. Does it
work?
Defective headphone
cable
YES
Replace the CPU board
NO
Follow the procedure step by step to correctly diagnose the problem. Take particular care with the
checks highlighted by circled numbers, which are described in detail below:
(1) Carry out the configuration procedure described in paragraph: 0“TV Standard”.
