Technogym GROUP CYCLE - Adjusting Vertical Play

15
A
A
B
B
A
A
C
C
D
D
D
D
Group Cycle
Adjusting play in the vertical adjustments
It is recommended you regularly check the play in the sliding mechanism,
because this can be the cause of vibrations and noise; it may also make
adjustment of the saddle or handlebar more dicult.
To adjust the play in the vertical sliding mechanism for the saddle and
handlebar:
- unscrew the screws (A)
- lift the cover (B);
- adjust screws (C) and (D) using an Allen key;
- check the play along the whole length of the saddle and handlebar;
- lower the cover (B);
- tighten the screws (A).
Tightening screws (C) and (D) (clockwise) makes sliding harder.
Loosening screws (C) and (D) (anticlockwise) makes sliding easier.
Turn the screws 1/8 turn at a time and check the ease of sliding before
making further adjustments.
