Group Cycle
Adjusting play in the horizontal adjustments
It is recommended you regularly check the play in the sliding mechanism,
because this can be the cause of vibrations and noise; it may also make
adjustment of the saddle or handlebar more dicult.
To adjust the play in the horizontal sliding mechanism for the saddle and
handlebar:
- unscrew the screw (A)
- lift the cover (B);
- adjust the nut (C);
- check the play along the whole length of the saddle and handlebar;
- lower the cover (B);
- tighten the screw (A).
If the nut is tightened (clockwise), sliding becomes harder.
If the nut is loosened (anticlockwise), sliding becomes easier.
Turn the nut 1/8 turn at a time and check the ease of sliding before making
further adjustments.
