Cable Jungle
3
E
3
4
C
2
1
D
B
A
C
Description of the equipment
A Frame: load-bearing structure of the equipment. The user stands in front of any of the four sides of the frame to perform the
exercises. On sides 2 and 4 there are high pulleys; on side 1 there is an adjustable output pulley; on side 3 there is a low pulley
and a high pulley.
B Adjustable cable outlet: adjust height using knob (D).
C Weight stacks: each pulley, operated by the user, moves the weights along two guide rails by means of a cable. A pin (E) is used
to select the workload, to adjust the exercise effort level.
