Cable Jungle
01083016
A
Lifting and moving the equipment
Use the four castor wheels (optional) to move the equipment.
If the equipment has already been anchored to the floor, it needs to be released
from the anchorage and its original feet refitted: follow the instructions in the
paragraph describing anchoring to the floor in reverse order.
WARNING
Move the equipment very carefully, because it may become unstable
and tip over.
The castors for moving the equipment snap on underneath the feet of the
equipment, after it has been raised, and are held in place by the special straps.
Raise the equipment using a pallet truck or fork-lift truck; and for greater safety
place a wedge under the frame to keep the equipment raised.
WARNING
We recommend placing padded material between the frame and the
wedge and between the frame and the machinery used to lift it.
Fit two of the wheels: fit the castor stems (A) into the holes provided under the
equipment feet, then push hard until they snap in.
