Sirio HH Compact
Instruction and maintenance manual
Page 12 di 24
Instruction n° 207 - Rev. 4 datel 19/10/2017
IT
Copyright © 2017TecmecS.r.l. Translated from the ORIGINAL instructions
D
in case of wall mounting go to step F
Proceed with the assembly of the
leveling feet and nuts.
Verify that the floor where the
dispenser will be installed, is leveled.
In case the dispenser is not stable,
adjust the 4 fleets and lock the
counter nuts.
If this procedure is not carried out, the resault could lead to noise, malfunctions,
abnormal wear of moving parts, and pose risks to the end user.
E
Secure the front panel using the self-
tapping screws.
F
Wall mounting
Add the spacer on the structure pillar,
and secure them by using the self-
tapping screw and washer .
