P-Mentor - Aircraft Flight Manual Page S01-14
1
st
Edition - Rev. 0
Section 9 - SUPPLEMENTS
S01 – AUTOPILOT GARMIN GFC500
4.3.3. APPROACHES
ILS APPROACH
This mode will only be available if the VHF and GPS navigators are
available.
1. NAV Source ..…....……..………………
Tune and activate the desired ILS
frequency
2. HSI Source ..…....……..………………
ENSURE that VHF NAV is the
selected navigation source
selecting CDI to VHF NAV
3. Course pointer …....……..……………..
SET CDI to front LOC course
4. APR Key ………….……………………..
PRESS
5. LOC and GS mode ...…………………..
VERIFY ARMED, CAPTURED
AND TRACKING
6. Altitude preselect ...………..…………..
SET Missed Approach Altitude
At decision Altitude (DA)
7. AP DISC button ..…....……..…………
PRESS, continue visually for
normal landing
OR
7. Missed Approach ..…....……..………..
PERFORM
Pressing the GA button will not disconnect the autopilot.
Select NAV or HDG mode to fly the missed approach
procedure.
If the Course Deviation Indicator (CDI) is greater than half
scale deflection, the autopilot will arm the LOC mode. The
pilot must ensure that the current heading will result in a
capture of the selected course. If the CDI is within half scale
deflection, the autopilot will enter the capture mode when the
APR key is pressed.
When the selected navigation source is an ILS, glideslope
coupling is automatically armed when the APR key is
pressed. The glideslope cannot be captured until the
localizer is captured. The autopilot can capture the
glideslope from above or below the glideslope.
