Wireless hybrid arm sy em
Wireless hybrid arm sy em
Program arming with exclusion of open zones
The procedure allows you to arm a program excluding open zones, after selecting the program to be armed, the OCG LED fl ashes indicating the
presence of open zones. The procedure is carried out in two stages
1 Select the program Move the key up to and away from the reading area, one or more times, until the desired program is selected
2 Exclude open zones Move the key up to the reading area, the OCG LED turns off and the program is armed excluding the open zones
The program and OCG
LEDs fl ash.
Courtesy light on
Program
status
LED
Operations
LED of the inserted
programs turned on.
Courtesy light on
The program LED
fl ashes fast.
Courtesy light on
Program selected
Program armed with open
Zones excluded
Program arming
Program LEDs off
Courtesy light on
Programs disarmed
Move the key close and wait for the
OCG LED to switch off
Move the key close, one or more times,
until the desired program is selected
Partial disarming of the programs armed
The procedure allows you to partially disarm the activated programs, partial disarming can only be performed by the keys enabled for this function
.
Partially disarm the programs Move the key enabled to perform partial disarming of programs close to the reading area
The program LEDs
fl ash slowly
Courtesy light on
Stato
programmi
Led
Operazioni
Programs partset
Partial disarming in
progress
Program LEDs on
Programs armed
Move the key close
The program LEDs
fl ash
Courtesy light on
