REFRIGERATED CABINETS PERFEKT | PERFEKT PLUS
EN
20
3.4. MAIN COMPONENTS
POS. ELEMENT NOTES
1 MAIN SWITCH
2 CONTROL PANEL
3 BLIND DOOR (or GLASS DOOR) Available with blind door or with glass door.
4 STEEL SUPPORT HOOKS FOR GRID
5 GRATING SURFACE
6 STAINLESS STEEL ADJUSTABLE FEET Optional: LOCKABLE WHEELS.
7 DOOR GASKET
8 LED LAMP For BLIND DOORS.
9 FAN STOP
10 DELIVERY GRID
11 SUCTION GRID
12 DOOR EDGE RESISTANCE Present in the BT version to prevent the door from freezing.
13 REFRIGERATING UNIT
14 IDENTIFICATION PLATE
The refrigerated cabinet door can be mounted on both sides. Should moving the door to the other side be required, the
appropriate KIT provided by the Manufacturer must be purchased. For the operating procedure, refer to paragraph “Door
disassembly and assembly on the other side”.
8 9
10
11
12
3
2
1
4
5
6
7
13
14
